RF Attenuators and Terminators

Engineered for precision and durability, RF Attenuators and Terminators help ensure optimal system performance and reliability by controlling power levels, stabilizing signal waveforms and reducing interference. These components are available with a broad range of options for configurations, connector interfaces, power level and frequency. They are designed for consistent operation in harsh environments subject to extreme temperatures and vibration.

RF Attenuators


RF Coaxial Attenuators

Protecting sensitive equipment and maintaining signal integrity by precisely controlling RF power, coaxial attenuators from Molex ensure reliable and repeatable performance at microwave and millimeter-wave (mmWave) frequencies up to 50 GHz. Rugged construction and multiple RF connector options support a variety of precision test-and-measurement, telecommunications and wireless applications.

Molex RF Coaxial Attenuators.

RF Chip Attenuators

Compact RF chip attenuators from Molex replace bulky discrete assemblies with lightweight surface-mount solutions, saving PCB space while ensuring precise and repeatable signal control at frequencies up to 18 GHz. Power-handling capability up to 5W, selectable attenuation and robust construction make these attenuators ideal for demanding aerospace, defense, wireless and medical applications.

Molex RF chip attenuators.

RF Terminators


RF Coaxial Terminators

Robust, high-precision RF coaxial terminators from Molex improve signal integrity and measurement accuracy in testing and communication applications subject to high mating cycles, extreme temperatures, shock and vibration. These terminators deliver low VSWR, tight 50-Ohm impedance matching at frequencies up to 65 GHz, multiple connector types and unit-traceable test data, improving versatility and repeatability.

Molex high-precision RF coaxial terminators with 2.92mm and SMA connectors.

Surface-Mount Terminations

Engineered to save PCB space and help eliminate bulky coaxial loads, flanges and heat sinks, surface-mount terminators from Molex provide low VSWR, precise impedance matching and reliable power handling at frequencies up to 12.4 GHz. These shock- and vibration-resistant terminators meet MIL-PRF/AEC-Q200 prequalification for dependable operation in harsh environments.

Molex Surface-Mount Chip Terminations.

Frequently Asked Questions


What is the difference between an RF attenuator and an RF terminator?

The difference between RF attenuators and RF terminators is that attenuators reduce (attenuate) RF signal power by a controlled amount, typically inline between system components, while terminators absorb RF energy at the end of a signal path, often an unused port or line endpoint. Both device types help maintain impedance matching, supporting signal integrity and overall RF system performance. Choosing an RF attenuator or an RF terminator depends on whether the goal is to reduce or absorb the RF signal.

Where are RF attenuators and terminators used?

RF attenuators and terminators are used in a wide variety of applications. These include wireless communications infrastructure, satellite communications, network equipment manufacturing and high-frequency/microwave-system applications. Both types of devices are also commonly used in test-and-measurement applications such as test-and-measurement laboratories, semiconductor testing setups and research-and-development facilities.

When should an RF attenuator be used instead of an RF terminator?

RF design engineers use attenuators when signal power levels need to be reduced to help prevent overdriving or damaging system components such as receivers, amplifiers or test equipment. Attenuating the power level is also useful for balancing signal power across an RF system. Terminators are useful for helping prevent reflections from unused ports or for supplying a matched load for an RF port, common challenges in testing, calibration and signal-distribution applications.

How do RF attenuators and terminators improve signal integrity?

RF attenuators and terminators improve signal integrity by managing undesirable signal reflections and supporting impedance matching. This reduces the distortion caused by impedance mismatches, stabilizes system performance and maintains waveform accuracy, improving system efficiency and the consistency of measurements. It also helps prevent excessive power levels or improper loading that can cause damage to sensitive RF equipment.

What factors should engineers consider when selecting RF attenuators and terminators?

Engineers must consider several factors when selecting the right RF attenuator or terminator for an application. These factors include frequency range and system impedance requirements, power-handling needs, measurement accuracy standards—sometimes with unit-traceable test data requirements—and application-specific performance goals. Engineers must also consider the connector interface type, attenuation value (for attenuators) and environmental operating conditions to ensure reliable operation.

What role do RF attenuators and terminators play in high-frequency and mmWave systems?

At microwave and mmWave frequencies, reflections and tight impedance matching become increasingly significant to ensure signal integrity and performance. High-precision RF attenuators and terminators are instrumental in delivering tight impedance matching, minimizing reflections and assisting with power management. This enables repeatable and accurate measurements, supports precise calibration and validation processes, and contributes to efficient and reliable operation in advanced communication and test systems.
